ART products · Software

art::ap

Advanced Performance. The higher-tier acoustic module for venues where the room has to do more than one thing convincingly.

what it does

Art::ap

The Room

Acoustic Performance, Not Acoustic Approximation

Every room has a character — a reverb, a density, a way it holds a sound after the source has stopped playing. ART::AP doesn't fight that character, it reshapes it: giving a venue exactly the acoustic it needs for the piece being performed, then handing it back the moment the show is over.

Why we call it ART::AP

  • True to the Room — 3D acoustic modeling and advanced reverb enhancement give precise control over room and density shaping, so the enhancement feels like the building, not a speaker.

  • Built for the Performer — powerful microphone input processing (equalizers, dynamics, feedback suppression) ensures every voice and instrument on stage is captured cleanly before it's ever enhanced.

  • Tuned, Not Guessed — a built-in speaker test engine with internal oscillator, plus advanced UDP metering, EQs, and level adjustments, means every room is calibrated on real measurement, not by ear alone.

One room, every acoustic. ART::AP turns a fixed architectural space into a flexible instrument — a concert hall on Friday, a lecture theatre on Monday, without moving a wall.

System Integration

  • Runs on the ART::DSP engine, controlled through ART::Director

Geometric Vector Engine

  • Patent-pending geometric vector engine — our proprietary algorithm for active acoustics enhancement

  • Room-Specific Acoustic Modeling — creates a unique 3D acoustic signature based on the room's passive properties, such as dimensions and materials

  • Hybrid Regenerative System — seamlessly optimizes natural reverberation to match the requirements of the event genre being staged







Spatial Shaping

  • Energy Distribution Control — independently steers sound energy projection from different source positions, whether from the stage or elsewhere, shaping the room's response differently across different zones of the same venue



Spectral Shaping

  • Customizable Spectral Balance — individually adjusts the tonal characteristics of the vector matrix and late-reverb layers

Performance Engine

  • Unlimited Acoustics Presets — configure and save presets for different source positions, content, and artistic preferences

  • Seamless Show Integration — synchronize with show-control systems via OSC

  • Smooth Preset Interpolation — seamless and immediate transitions between presets during live performances

  • Detailed Acoustic Control — adjust all acoustic parameters in real time via OSC, for unmatched flexibility

Input Processing & Calibration

  • Microphone input processing — equalizers, dynamics, and feedback suppression

  • Speaker test engine with internal oscillator for calibration

  • Advanced UDP metering with precision control, 8-band EQs, level adjustments, and vector sizing

Geometric Multi-Channel Reverb Engine

  • Controls reverberation time and further ISO 3382 room acoustic parameters

  • High-Resolution Reverb — neutral Feedback Delay Networks (FDN) generate up to 128 channels of high-resolution, decorrelated algorithmic reverb

  • Passive Room Integration — merges the room's existing natural reverb with the generated reverb into one unified, naturally perceived room sound

  • Advanced Parameter Control — adjusts time structure, density, envelopment, shape, and spectral parameters for precise acoustic tuning


Temporal Shaping

  • Targeted Reflections — enhances volume and reflections exactly where needed

  • Adjustable Room Dimensions — geometrically scales room size, wall, and ceiling arrangement, with tailored adaptations for ADA (Acoustically Different Area) zones such as under balconies or boxes

Voice Lift

  • Optimized Voice Distribution — advanced algorithms guarantee clear, even voice projection; this is the module ART::VoiceLift is built on

Effect Presets

  • Dynamic Acoustic Effects — pre-configured presets for specific scenes: cave-like echoes, outdoor-style acoustics, or dramaturgical effects

Brand agnostic and built to fit an existing rack. See the full list on the Integrations page →
